10 Kwh Lithium Solar Battery 6000 Cycles New 48V
Additional information
Loading
Description
This is the Brand new 2022 Lithium Wall mounted Solar battery • LifePo4 technology • 6000 recharge cycles • 5 year warranty • UL listed • Tested to exceed standard performances • 51v @ 210ah tested • Burn in tested • Discharge Tested • Triple burn in to ensure 100% quality and that user expectations are exceeded.
• New Case design the Mini series now is square with curved corners • 6lbs lighter than previous models • Cleaner faster BMS provides easy long lasting performance of the battery without customer interaction. • 20.5? x 20.5? square 9? thick (without wall mount bracket) • Chrome plated handles on the side for easy installation. • Front display is brighter than previous and now offers faster refresh times.
• 4 button interaction allows user to monitor cell voltage, battery capacity, charge rate, battery voltage and more. • RS232 bottom port includes USB to RS232 cable to connect a laptop or desktop computer with windows to the battery for advanced monitor, configuration, and over all performance checks. • no more bottom dc breaker switch needed. Internal bms now watches for short circuit, overload, under voltage and voltage leakage and will disconnect battery in any of those scenarios automatically. • Power button on off switch added • Dry contact option for normally open during fault or normally open/closed with battery voltage is low for external charging interaction.
• Grounding point added to bottom • low profile power connections •1 meter long power cables included with ring terminals on the end that fit most major brand inverters • Can Bus standard communication bms protocol • RS485 BMS connections • BMS cable included • Prismatic 15 cell design • 200AH rated • 48v • 10kwh of storage • Operation voltage 48-51v • low cut off voltage 37.5-42v • max cut off voltage 52.5-55.5v • contact current 40A charge time average 5-6hours • 100A max continuous current discharge • -20C – 60C temperature range • Weight 82KG • 8 Way Protection • Cell balancing built in • Data logging built in. • Model YL-W48200 • can be rack mounted or wall mounted also can lay flat or vertical. Ships in a wood crate.
https://buycheapsolar.com/shop/solar-batteries/new-2022-mini-series-10kwh-bsc-lithium-wall-mountbattery/
• New Case design the Mini series now is square with curved corners • 6lbs lighter than previous models • Cleaner faster BMS provides easy long lasting performance of the battery without customer interaction. • 20.5? x 20.5? square 9? thick (without wall mount bracket) • Chrome plated handles on the side for easy installation. • Front display is brighter than previous and now offers faster refresh times.
• 4 button interaction allows user to monitor cell voltage, battery capacity, charge rate, battery voltage and more. • RS232 bottom port includes USB to RS232 cable to connect a laptop or desktop computer with windows to the battery for advanced monitor, configuration, and over all performance checks. • no more bottom dc breaker switch needed. Internal bms now watches for short circuit, overload, under voltage and voltage leakage and will disconnect battery in any of those scenarios automatically. • Power button on off switch added • Dry contact option for normally open during fault or normally open/closed with battery voltage is low for external charging interaction.
• Grounding point added to bottom • low profile power connections •1 meter long power cables included with ring terminals on the end that fit most major brand inverters • Can Bus standard communication bms protocol • RS485 BMS connections • BMS cable included • Prismatic 15 cell design • 200AH rated • 48v • 10kwh of storage • Operation voltage 48-51v • low cut off voltage 37.5-42v • max cut off voltage 52.5-55.5v • contact current 40A charge time average 5-6hours • 100A max continuous current discharge • -20C – 60C temperature range • Weight 82KG • 8 Way Protection • Cell balancing built in • Data logging built in. • Model YL-W48200 • can be rack mounted or wall mounted also can lay flat or vertical. Ships in a wood crate.
